Industrial Cutting Applications For Strawberries

Urschel® Laboratories offers fruit processing equipment manufactured with the fresh fruit industry and canners in mind. Simple to maintain and operate. Gentle cutting operation encourages extended shelf-life and delivers quality cuts.

Note: Hundreds of pounds per hour up to thousands of pounds per hour; capacities vary depending on condition of materials, method of feeding, and other variables. Where capacities are listed, it is assumed product will flow in a smooth, uninterrupted manner through an Urschel® machine that is in optimum condition. Capacities listed are an indication of potential results.

Below you will find our selection of strawberry processing machines. Each of the following fruit cutting machines offers different kinds of cuts.

Slicers

Dicers

Sprint 2® Dicer

Dicers

Dice | Strip
Processing of strawberries and other berries on the SPRINT 2 DICER — 1/8 up to 1″ (3.2 up to 25.4 mm) cubes and pieces from fresh, tempered frozen, or thawed berries. Use conveyor discharge version for optimal controlled, complete, gentle discharge of cut product to reduce waste. Accepts product input up to 6.5″ (165.1 mm) in any dimension. Offers more power versus the DiversaCut Sprint Dicer. More power equals potentially higher capacities.

DiversaCut Sprint® Dicer

Dicers

Dice | Strip
Processing of strawberries and other berries on the DiversaCut Sprint Dicer — 1/8 up to 1″ (3.2 up to 25.4 mm) cubes and pieces from fresh, tempered frozen, or thawed berries. Maximum infeed is 6.5″ (165.1 mm) in any dimension.
Features a 1.5 HP (1.1 kW) with soft start. The DiversaCut Sprint Dicer is the smallest dicer in the DiversaCut series and the precursor to the Sprint 2 Dicer.

Affinity Integra® Dicer

Dicers

Shredders

Milling Equipment

Comitrol® Processor Model 1500

Milling Equipment

Puree
A wide range of particle sizes suitable for jam, jelly, pastry fillings, and juice extraction can be obtained from fresh, frozen, or cooked berries. Choose from wide selection of cutting head opening sizes for particle sizes larger than 1/64″ (0.4 mm). Approximate hourly capacity of 1/16″ (1.6 mm) particles using 5,634 revolutions per minute impeller speed and 17″ cutting enclosure: 7,500 lb (3,400 kg). Use microcut heads for the finest degree of reduction at capacities up to 12,000 lbs. (5,500 kg) hourly using 9,390 revolutions per minute impeller speed and 30 horsepower motor. Chop or grind whole berries and pump into the Processor for minimum aeration.

Comitrol® Processor Model 1700

Milling Equipment

Coarse Puree | Puree
A wide range of particle sizes suitable for jam, jelly, pastry fillings, and juice extraction can be obtained from fresh, frozen, or cooked berries. Choose from wide selection of cutting head opening sizes for particle sizes larger than 1/64″ (0.4 mm). Approximate hourly capacity of 1/16″ (1.6 mm) particles using 5,634 revolutions per minute impeller speed and 17″ cutting enclosure: 7,500 lb (3,400 kg). Use microcut heads for the finest degree of reduction at capacities up to 12,000 lb (5,500 kg) hourly using 9,390 revolutions per minute impeller speed and 30 horsepower motor. Chop or grind whole berries and pump into the Processor for minimum aeration.

Others

M VersaPro® Dicer
