Soy

Butter | Flake | Milk | Paste | Slurry
​Slices .020 to .050″ (0.5 to 1.3 mm) from dry soy beans conditioned with moist heat to minimize fracture. Sharp, renewable edge inserts of the Comitrol Processor slicing head cut cleanly without hull separation. Capacity is 3,000 lb (1,300 kg) of .010″ (0.3 mm) thick slices using 3,600 revolutions per minute impeller speed and 15 horsepower motor.
Produce particles as small as 200 mesh sieve size from extracted soy bean flakes in aqueous slurry. Use suitable microcut heads in two or more reduction steps for finest particles. Capacities of 10 to 30 gallons (35 to 110 liters) per minute to produce soya bean milk will depend upon desired particle size and method of feeding product to the Processor.
Use to prepare slurry prior to extruder. Use after extruder to achieve final particle size. Use to size reduce off-grade product for rework. Such products as dough, cereal, feed products, soy beans, soy protein, pet food ingredients, noodles, and snack products

Flake | Granulate | Milk | Paste | Puree | Shred | Slice | Slurry
​Slices .020 to .050″ (0.5 to 1.3 mm) from dry soy beans conditioned with moist heat to minimize fracture. Sharp, renewable edge inserts of the Comitrol Processor slicing head cut cleanly without hull separation. Capacity is 3,000 lbs. (1,300 kg) of .010″ (0.3 mm) thick slices using 3,600 revolutions per minute impeller speed and 15 horsepower motor.
Produce particles as small as 200 mesh sieve size from extracted soy bean flakes in aqueous slurry. Use suitable microcut heads in two or more reduction steps for finest particles. Capacities of 10 to 30 gallons (35 to 110 liters) per minute to produce soya bean milk will depend upon desired particle size and method of feeding product to the Processor.
Use to prepare slurry prior to extruder. Use after extruder to achieve final particle size. Use to size reduce off-grade product for rework. Such products as dough, cereal, feed products, soy beans, soy protein, pet food ingredients, noodles, and snack products.

Coarse Puree | Flake | Granulate
​Process direct after the extruder extruded protein into uniform flakes which rehydrate quickly and blend readily into finished products.

Paste | Milk | Puree
Reduce paste for milk extraction.

Coarse Puree | Flake | Granulate
​Process direct after the extruder extruded protein into uniform flakes which rehydrate quickly and blend readily into finished products.

Coarse Puree | Flake | Granulate
​Process direct after the extruder extruded protein into uniform flakes which rehydrate quickly and blend readily into finished products.

Butter | Liquefy | Milk | Paste | Puree
Reduce soy nut slurry into a fine soy nut butter or soy milk consistency.
Produce a soybean slurry from raw soybeans and water.
Use to prepare slurry prior to extruder. Use after extruder to achieve final particle size. Use to size reduce off-grade product for rework. Such products as dough, cereal, feed products, soy beans, soy protein, pet food ingredients, noodles, and snack products.
Single pass reduction on the Comitrol Processor Model 9310 will produce similar particles at capacities up to 70 gallons (320 liters) per minute without multiple reduction steps.
The 9310 offers a built-in HMI and features the highest capacity in the Comitrol line. The 9310 features the highest capacity with the most powerful motor combined with the largest microcut head configuration.
