Onions

Slice
Process onions on the Urschel CC Slicer: 1/16 to 1/8″ (1.6 to 3.2 mm) slices from onions not exceeding 3-3/4″ (95 mm) in diameter. Parts are available for slice thickness up to 5/16″ (7.9 mm). Onions should be topped and tailed and peeled. Use stainless steel contact parts and 2 horsepower motor with drive for 342 revolutions per minute impeller speed. Note: Centrifugal slicing principle of the CC Slicer does not provide for complete orientation of onions so that rings will be produced. A reasonable percentage of slices will be transverse to the axis of the onion resulting in rings, while other slices may be parallel to the axis.

Dice | Strip
The DiversaCut 2110A® Dicer, equipped with a 5 or 10 HP (3.7 or 7.5 kW) motor provides the highest capacity in the DiversaCut® series.

Dice | Strip
Processing of onions on the Sprint 2 Dicer – 1/8 up to 1″ (3.2 up to 25.4 mm) dices and various strips of onion. Remove any tough, outer skin to minimize accumulation on knife edge. ​Use conveyor discharge version for optimal controlled, complete, gentle discharge of cut product to reduce waste. Accepts product input up to 6.5″ (165.1 mm) in any dimension – precut product as necessary. Offers more power versus the DiversaCut Sprint Dicer. More power equals potentially higher capacities.

Dice | Strip
Processing of onions on the DiversaCut Sprint Dicer – 1/8 up to 1″ (3.2 up to 25.4 mm) dices and various strips of onion. Remove any tough, outer skin to minimize accumulation on knife edge. Accepts product input up to 6.5″ (165.1 mm) in any dimension – precut product as necessary. Features a 1.5 HP (1.1 kW) with soft start. The DiversaCut Sprint Dicer is the smallest dicer in the DiversaCut series and the precursor to the Sprint 2 Dicer.

Chop | Dice | Granulate
AFFINITY INTEGRA DICER — Offers dices ranging from 1/8 up to 1/2″ (3.2 up to 12.7 mm) and various strips. Accepts in-feed products up to approximately 4.5″ (114 mm).

Coarse Puree | Paste | Puree
​Use microcut heads for the finest degree of reduction at capacities up to 12,000 lb (5,500 kg) hourly using 9,390 revolutions per minute impeller speed and 30 horsepower motor. Chop or grind product 1/4″ (6.4 mm) or smaller and pump into the Processor for minimum aeration.

Coarse Puree | Paste | Puree
A full range of particle sizes suitable for blending or subsequent processing can be obtained from onions diced or precut into 1/2″ (13 mm) pieces. Choose from wide selection of cutting head opening sizes for particle sizes larger than 1/64″ (0.4 mm). Capacity is 3,500 lbs. (1,500 kg) of 1/16″ (1.6 mm) particles hourly using 3,600 revolutions per minute impeller speed 17″ cutting enclosure. Use microcut heads for finest degree of reduction at capacities up to 12,000 lbs. (5,500 kg) hourly using 9,390 revolutions per minute impeller speed and 30 horsepower motor. Chop or grind product 1/4″ (6.4 mm) or smaller and pump into the Processor for minimum aeration.

Coarse Puree | Paste
​A full range of particle sizes from coarse chopped to smaller particles suitable for blending or subsequent processing can be obtained from separated and cleaned, peeled, or fresh onions, or onion scraps. Choose from wide selection of cutting head opening sizes for particle sizes larger than 1/64″ (0.4 mm). Capacity is 3,500 lb (1,500 kg) of 1/16″ (1.6 mm) particles hourly using 3,600 revolutions per minute impeller speed. Use as a pre-cutter for further processing through the Microcut Head on the Comitrol® Processor Model 1700 when a smoother consistency is required.

Coarse Puree | Paste
​A full range of particle sizes from coarse chopped to smaller particles suitable for blending or subsequent processing can be obtained from separated and cleaned, peeled, or fresh onions, or onion scraps. Choose from wide selection of cutting head opening sizes for particle sizes larger than 1/64″ (0.4 mm). Capacity is 3,500 lbs. (1,500 kg) of 1/16″ (1.6 mm) particles hourly using 3,600 revolutions per minute impeller speed. Use as a pre-cutter for further processing through the Microcut Head on the Comitrol® Processor Model 1700 when a smoother consistency is required.

Slab
Process onions on the VSC Segment Cutter by Urschel such as .188, .250, .375 or .500″ (4.8, 6.4, 9.0 or 13 mm) slab sizes from peeled and trimmed onions with trimmed 2″ (51 mm) flat surface fed on flat belt to Model VSC.
