Ham (Cured)

Dice | Strip
Ham processing on the M VersaPro Dicer (MVP) includes 3/16 to 3″ (4.8 to 76 mm) squares or pieces such as 3/8 x 1″ (9.5 x 25 mm) or 3/4 x 1-1/2″ (19 x 38 mm).
The MVP offers 33% increased feeding capacity versus the standard M6 due to wider belts, optimized cutting, and increased horsepower. Optional HMI is also available.

Dice | Strip
Processing of ham chubs, logs, or roasts. The DiversaCut 2110A® Dicer may produce 1/8 to 1″ (3.2 to 25.4 mm) cubes or dices and pieces such as 1/8 x 5/32 x 1″ (3.2 x 4 x 25.4 mm) from cooked, frozen-tempered product such as ham roasts. Approximate hourly capacity of 1/2″ (12.7 mm) dice: 6,500 lb (3,000 kg).

Cube | Dice | Strip
Processing of ham using the SPRINT 2 DICER —  1/8 up to 1″ (3.2 up to 25.4 mm) cubes, and various strips. ​Use conveyor discharge version for optimal controlled, complete, gentle discharge of cut product to reduce waste. Accepts product input up to 6.5″ (165.1 mm) in any dimension – precut product as necessary. Offers more power versus the DiversaCut Sprint Dicer. More power equals potentially higher capacities.

Cube | Dice | Strip
Processing of ham using the DiversaCut Sprint Dicer —  1/8 up to 1″ (3.2 up to 25.4 mm) cubes, and various strips. ​The DiversaCut Sprint Dicer features a 1.5 HP (1.1 kW) with soft start. The DiversaCut Sprint Dicer is the smallest dicer in the DiversaCut series and the precursor to the Sprint 2 Dicer.

Dice | Strip
AFFINITY® DICER —  1/8 up to 3/4″ (3.2 up to 19 mm) dices and wide-range of strip cuts. Specifically manufactured for difficult to process products such as cold temperature applications, soft-texture products, or products with a  high-fat content that would normally be difficult to cut. Offers the highest capacity among Urschel dicers. Three models available. The Affinity Dicer with built-in log cutter offers an all-in-one solution for preformed logs and chubs.

Dice | Strip
AFFINITY INTEGRA DICER — Offers dices ranging from 1/8 up to 1/2″ (3.2 up to 12.7 mm) and various strips. Accepts in-feed products up to approximately 4.5″ (114 mm).

Dice | Strip
Ham processing on the Urschel Model M6 Dicer includes 3/16 to 3″ (4.8 to 76 mm) squares or pieces such as 3/8 x 1″ (9.5 x 25 mm) or 3/4 x 1-1/2″ (19 x 38 mm). Ham must be presliced so thickness does not exceed 1″ (25 mm). Approximate hourly capacity: 4,500 lb (2,000 kg). Consult Urschel Laboratories for optimum knife configuration and cutting speed.

Flake
​A wide range of particle sizes for soups, spreads, infant feeding, and special diet requirements. Use cooked or uncooked ham precut for rapid feeding into 2 or 3″ high cutting heads. Choose from wide selection of cutting head opening sizes for particle sizes larger than 1/64″ (0.4 mm).

Flake
​A wide range of particle sizes for soups, spreads, infant feeding, and special diet requirements. Use cooked or uncooked ham precut for rapid feeding into 2 or 3″ high cutting heads. Choose from wide selection of cutting head opening sizes for particle sizes larger than 1/64″ (0.4 mm).
