Cereal and Grains

Coarse Puree | Flour | Grind | Puree
Reduce products like wet milled oat bran into a smooth flowing, fine puree. Use microcut heads to obtain particles of 100 mesh or smaller. Use of air classification system following the Comitrol Processor allows over-size particles to be separated and rerun. Slice dry grains lengthwise using the Comitrol Processor slicing head. Sharp, renewable edge inserts cut each grain cleanly with minimum hull separation and damage. Capacity is 2,500 lb (1,150 kg) hourly at .050″ (1.3 mm) slice thickness using 1,800 revolutions per minute impeller speed and 10 horsepower motor.

Flour particles in 60 to 120 mesh sieve range from whole, broken or second-head dry rice. Use microcut head with 9,390 revolutions per minute impeller speed, 30 horsepower motor and 17″ cutting chamber. Air classification system following the Comitrol Processor allows oversize particles to be separated and rerun. Capacity is 3,000 to 4,000 lb (1,350 to 1,800 kg) hourly using any suitable controlled feeding method.

Produces a uniform particle size with excellent appearance and texture for the production of snack foods and other masa products. Consult Urschel for desired particle size information.

Coarse Puree | Granulate | Grind | Puree
1/32″ (0.8 mm) or larger particles suitable for rework. Feed the rejects and returns into style cutting head of selected opening size. Approximate hourly capacity: 1,000 to 3,500 lb (450 to 1,500 kg) using 3,600 revolutions per minute impeller speed on the Comitrol® Processor Model 1700.
Produce particles from 18 to 50 mesh sieve using cutting heads with suitable openings. Capacity is 1,200 to 2,800 lbs. (540 to 1,250 kg) hourly at 3,600 revolutions per minute impeller speed and 17″ cutting enclosure. Use microcut heads to obtain particles of 100 mesh or smaller. Use of air classification system following the Comitrol Processor allows over-size particles to be separated and rerun. Slice dry grains lengthwise using the Comitrol Processor slicing head. Sharp, renewable edge inserts cut each grain cleanly with minimum hull separation and damage. Capacity is 2,500 lbs. (1,150 kg) hourly at .050″ (1.3 mm) slice thickness using 1,800 revolutions per minute impeller speed and 10 horsepower motor.
Flour particles in 60 to 120 mesh sieve range from whole, broken, or second-head dry rice. Use microcut head with 9,390 revolutions per minute impeller speed, 30 horsepower motor and 17″ cutting chamber. Air classification system following the Comitrol Processor allows oversize particles to be separated and rerun. Capacity is 3,000 to 4,000 lbs. (1,350 to 1,800 kg) hourly using any suitable controlled feeding method.
​Produces a uniform particle size with excellent appearance and texture for the production of snack foods and other masa products. Consult Urschel Laboratories or your Urschel representative for desired particle size information

Granulate | Rework
​Produce medium to coarse granulations. Approximate hourly capacity: 1,000 to 3,500 lb (450 to 1,500 kg) using 3,600 revolutions per minute impeller speed.

Granulate
The N Granulator provides granulations of 1/8, 5/32, 3/16, 1/4, 3/8, or 1/2″ (3.2, 3.9, 4.8, 6.4, 9.5, or 12.7 mm) with set circular knife spindle spacing for the reduction of dry cereal such as corn flakes.
