Sorting table with vibration
Preparing, Conveying
The sorting table with vibration can also be combined with the GEWA washing machines and enables the pre-sorting and pre-dewatering of products.
- Features
- Specs
- Resources
Overview
Pre-sorting and initial dewatering by means of vibration
The sorting table with vibration can be optimally combined with a GEWA washing machine. The vibration function ensures that the products are dewatered while being conveyed across the table and that fine particles are separated from the good product. Different hole sizes are available to enable the table to be adapted to various products. The vibrating screen can be replaced quickly and easily.
The table is equipped with a collecting tray underneath the vibrating screen with a central drain pipe. It also includes fresh water showers for spraying the products.
Optionally, a sloping version of the sorting table is available.
Your Benefits
- Easy changing of the vibrating screen for adjustment to different products
- Robust construction made completely of stainless steel
Specs
| Loading Type | Continuous |
| Dimensions | L x W x H: 1,675 x 1,105 x 1,759 to 1,837 x 1,404 x 1,714 mm (66 x 43.5 x 69.3 to 72.3 x 55.3 x 67.5″) Weight: Depending on the configurations Belt width: 480–780 mm (18.9– 30.7″) |
Industries
Vegetables
Resources
Brochures
Sorting Table with Vibration
